[N614] ☆ Lenovo Enterprise-class Gigabit Ethernet data center switch　G7028 (7159-HCP)☆

收藏该商品

[N614] ☆ Lenovo Enterprise-class Gigabit Ethernet data center switch　G7028 (7159-HCP)☆: 商品编号：h1139488670 【浏览原始网页】

当前价：RMB 402

加价单位：250日元

日元：8000.00円消费税：10% 什么是消费税？商品消费税由日本政府收取的，YAHOO店铺出品的拍卖商品，需要您支付消费税（一般为商品得标金额的10%），个人卖家无需支付消费税。

出价：0次直购价：RMB 912.74

账户升级，享受无限制出价！《会员制说明》

商品件数：1

商品成色：其他

日本邮费：买家承担

可否退货：不可以

开始时间：2025-10-03 15:46:45

结束时间：2025-10-09 20:26:59

自动延长：有可能

提早结束：有可能

商品详情参考翻译下标记录新手必读

划词翻译上线，鼠标选择文字自动翻译,翻译内容仅供参考，如有疑问请咨询小觅翻译。

出品商品	メーカー：Lenovo 商品名 / 型番：Enterprise-class Gigabit Ethernet data center switch　G7028 (7159-HCP) 付属品：なし程度：中古品になります。キズ・スリキズがあります。状態：通電～コンソール出力の確認となります。コンソール出力結果は次項を参照ください。
お取引について	出品物は写真に写っている物のみです。取り引きはノークレーム・ノーリターンでお願いします。お使いのパソコンの使用状況によっては実物と色が異なる場合があります。神経質な方は入札をお控え下さい。
お支払い金額	お支払い金額は、落札金額＋消費税＋送料(税込)をお支払いください。 ※当店はオークションストアの為、落札金額に消費税が別途必要になります。
発送方法	発送方法は、佐川急便の飛脚宅配便(元払い)か、クロネコヤマトの宅急便(元払い)になります。送料(税込)は以下になります。・佐川急便　　北海道　　　　　　　　　　　　2550円　　北東北・九州　　　　　　　　　2200円　　南東北・中国・四国　　　　　　2100円　　関東・信越・北陸・中部・関西　2050円　※沖縄・その他離島の場合の送料は入札の前にお問い合わせください。・クロネコヤマト　　北海道　　　　　　　　　　　　2800円　　北東北・九州　　　　　　　　　2400円　　南東北・中国・四国　　　　　　2300円　　関東・信越・北陸・中部・関西　2200円　　沖縄　　　　　　　　　　　　　4800円
発送について	入金確認が出来ましたら2～3営業日後に発送します。商品を発送しましたらご連絡致します。

コンソール

U-Boot 2009.06 (Apr 09 2015 - 01:22:14)

CPU: P1010, Version: 1.0, (0x80f10010)
Core: E500, Version: 5.1, (0x80212151)
Clock Configuration:
CPU0:800 MHz,
CCB:400 MHz,
DDR:400 MHz (800 MT/s data rate) (Asynchronous), IFC:100 MHz
L1: D-cache 32 kB enabled
I-cache 32 kB enabled
Board: Rack Switch G7028, CPLD: V5, PCBA: V2
I2C: ready
DRAM: Configuring DDR for 800 MT/s data rate
512 MB

Memory Test ..........

Production Mode

FLASH: 32 MB
L2: 256 KB enabled
NAND: 256 MiB
PCIe1: Root Complex of mini PCIe Slot, no link, regs @ 0xffe0a000
PCIe1: Bus 00 - 00
PCIe2: Root Complex of PCIe Slot, x1, regs @ 0xffe09000
PCIe2: Bus 01 - 02
Net: eTSEC2: No support for PHY id 0; assuming generic
eTSEC1: No support for PHY id ffffffff; assuming generic
eTSEC2 [PRIME], eTSEC1

Booting OS

Wed Jun 5 04:22:26 UTC 2024
Booting image '1'

Initializing Production Mode .....
Early Initialization Done. (3 secs)
256MB w/2048-128KB sectors
PCI unit 0: Dev 0xb321, Rev 0x12, Chip BCM56321_B1, Driver BCM56334_B0

Rebooted because of power cycle.

Jun 5 4:22:46 0.0.0.0 CRIT system: Redundant Power Supply not Installed
Booting complete 4:23:27 Wed Jun 5, 2024:
Version 8.1.1 from FLASH image1, factory default configuration.

Lenovo RackSwitch G7028.

Enter password:
Jun 5 4:23:27 192.168.49.50 INFO system: booted version 8.1.1 from FLASH image1, factory default configuration

Jun 5 4:23:27 192.168.49.50 INFO system: Assigned default IP 192.168.49.50 to data interface

Jun 5 4:23:27 192.168.49.50 INFO system: Assigned default IP 192.168.50.50 to mgmt interface

Jun 5 4:23:27 192.168.49.50 ALERT system: coldStart

Enter password:

RS G7028>en

Enable privilege granted.
RS G7028#show system
System Information at 4:23:41 Wed Jun 5, 2024
Time zone: No timezone configured
Daylight Savings Time Status: Disabled

Lenovo RackSwitch G7028

Switch has been up for 0 days, 0 hours, 1 minute and 18 seconds.
Last boot: 4:22:42 Wed Jun 5, 2024 (power cycle)

MAC address: a4:8c:db:0d:ce:00 IP (If 1) address: 192.168.49.50
Management Port MAC Address: a4:8c:db:0d:ce:fe
Management Port IP Address (if 4): 192.168.50.50
Hardware Part No: 00VX091
Switch Serial No: Y030PZ63W019
Manufacturing date: 16/14

MTM Value: 7159-HCP
ESN: MM08482

Software Version 8.1.1 (FLASH image1), factory default configuration.
Boot kernel version 8.1.1

USB Boot: disabled

Temperature MAC : 28 C
Temperature 10G PHY : 28 C
Temperature CPU : 24 C
Press q to quit, any other key to continue Temperature Air Inlet : 23 C
Temperature 1G PHY : 27 C
Temperature Air Outlet : 29 C

System Warning at 60 C / Shutdown at 65 C / Set Point is 45 C

Fan 1 : RPM=9000 PWM=100% Back-To-Front
Fan 2 : RPM=9000 PWM=100% Back-To-Front
Fan 3 : RPM=9000 PWM=100% Back-To-Front

System Fan Airflow: Back-To-Front

Internal Power Supply: On
Redundant Power Supply: Not Installed

Power Faults: ()
Fan Faults: ()
Service Faults: ()

Current idle CLI timeout: 10 minutes
Current linkscan mode: normal
System will reset on crash
System will log packets sent to the CPU
Use of BOOTP for configuration currently enabled
Use of DHCP for MGT interface configuration currently enabled
Use of default-ip for DATA interface configuration currently enabled
Use of default-ip for MGT interface configuration currently enabled
Display hostname (sysName) in CLI prompt currently disabled
Syslog console enabled
Syslog severity level of console output 6
Press q to quit, any other key to continue Syslog severity level of write to flash 7
ErrDisable recovery disabled, timeout 300 sec
Port-based Port Mirroring currently disabled
IP Forwarding currently OFF
NTP currently OFF
RADIUS authentication currently OFF
TACACS+ authentication currently OFF
LDAP Authentication currently OFF
Service Required LED currently disabled
USB inserted and ready: no
Current SNMP params:
Read community string: "public"
Write community string: "private"
SNMP state machine timeout: 5 minutes
Trap source address: 192.168.49.50
Authentication traps disabled.
All link up/down traps enabled.

Current SNMP trap hosts:

Current System Access settings:

IP Management currently allowed from *ALL* IP addresses

Usernames:
Press q to quit, any other key to continue user - disabled - offline
oper - disabled - offline
admin - enabled - online 1 session.
Current User ID table:

Current strong password settings:
strong password status: disabled

HTTP access currently enabled on TCP port 80
HTTPS server access currently disabled on TCP port 443
SNMP access currently read-write
User configuration from BBI currently disabled
Telnet/SSH access configuration from BBI currently disabled
Telnet access currently enabled on TCP port 23
TFTP occurs over port 69
RS G7028#show version
System Information at 4:23:52 Wed Jun 5, 2024
Time zone: No timezone configured
Daylight Savings Time Status: Disabled

Lenovo RackSwitch G7028

Switch has been up for 0 days, 0 hours, 1 minute and 28 seconds.
Last boot: 4:22:42 Wed Jun 5, 2024 (power cycle)

MAC address: a4:8c:db:0d:ce:00 IP (If 1) address: 192.168.49.50
Management Port MAC Address: a4:8c:db:0d:ce:fe
Management Port IP Address (if 4): 192.168.50.50
Hardware Part No: 00VX091
Switch Serial No: Y030PZ63W019
Manufacturing date: 16/14

MTM Value: 7159-HCP
ESN: MM08482

Software Version 8.1.1 (FLASH image1), factory default configuration.
Boot kernel version 8.1.1

USB Boot: disabled

Temperature MAC : 28 C
Temperature 10G PHY : 28 C
Temperature CPU : 24 C
Press q to quit, any other key to continue Temperature Air Inlet : 23 C
Temperature 1G PHY : 28 C
Temperature Air Outlet : 28 C

System Warning at 60 C / Shutdown at 65 C / Set Point is 45 C

Fan 1 : RPM=9000 PWM=100% Back-To-Front
Fan 2 : RPM=9000 PWM=100% Back-To-Front
Fan 3 : RPM=9000 PWM=100% Back-To-Front

System Fan Airflow: Back-To-Front

Internal Power Supply: On
Redundant Power Supply: Not Installed

Power Faults: ()
Fan Faults: ()
Service Faults: ()

RS G7028#
